100W RF Connectorized Power Amplifier Module For Communication Radar System

Name: 100W RF Connectorized Power Amplifier Module For Communication Radar System
Brand: Nengxun Communication Technology Co.,Ltd.
SKU: NXPA1.5MHZ-30MHz 100W
Price: 2,250.00 USD
Availability: InStock

Product Details

Place of Origin: CHINA

Brand Name: NENGXUN

Model Number: NXPA1.5MHZ-30MHz 100W

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: The price is negotiable

Packaging Details: 25.6*111.7*17MM

Delivery Time: 5-8DAYS

Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability: 10000

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                100W Power Amplifier Module, RF Radar Power Amplifier Module, 100W rf connectorized module


Frequency:	1.5MHz~30MHz	Max Output Power (CW):	≥ 50dBm
Dimensions(mm)/Weight:	≤196.5×99×26.5mm (without Connectors), ≤1.8KG	Installation Method:	Radiator Shall Be Installed For Power Amplifier Test

Frequency:	1.5MHz~30MHz
Max Output Power (CW):	≥ 50dBm
Dimensions(mm)/Weight:	≤196.5×99×26.5mm (without Connectors), ≤1.8KG
Installation Method:	Radiator Shall Be Installed For Power Amplifier Test

100W RF Connectorized Power Amplifier Module For Communication Radar System

PN:NXPA1.5-30MHz100W

Small size, Low power consumption, good stability;
High linearity and Intermodulation;
Shape structure can be customized
Products can be developed according specification;
Widely used in Radar, Navigation, Communication, EMC test and other Civil fields.

100W RF Connectorized Power Amplifier Module For Communication Radar System 0

Technical Data

Parameters
Frequency	1.5MHz~30MHz
Max output Power (CW)	≥ 50dBm
Gain	≥ 50dB (customized)
Gain Flatness	≤ 2±1dB
Input VSWR	≤ 1.6
Input power	0±2dBm
Max Input	+6dBm
Temperature protection	Over 80℃ protection,with open circuit protection
PTT port	Default off; 3.3~5V on
VCC/Current reference	28V/15A
Working voltage	+28V~ +32V
Working current	≤ 9~12.5A
Spurious	≤ -65dBc
Harmonic	≤ -10dBc
Operating Temperature	-30℃~+55℃
RF Connector	RFin-SMA-F/ RFout-N-K
Power Supply Interface	feedthru capacitor
Dimensions(mm)/Weight	≤196.5×99×26.5mm (without connectors), ≤1.8KG
Installation method	Radiator shall be installed for power amplifier test
Package	1pcs/box
