Name: OEM RF UHF VHF Power Amplifier Module NXPA8.8-9.6GHz-50W
Brand: Nengxun Communication Technology Co.,Ltd.
SKU: NXPA7.7-8.5GHz-50W
Price: 2,250.00 USD
Availability: InStock

Product Details

Place of Origin: CHINA

Brand Name: NENGXUN

Model Number: NXPA7.7-8.5GHz-50W

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: The price is negotiable

Packaging Details: 25.6*111.7*17MM

Delivery Time: 5-8DAYS

Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability: 10000

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                OEM vhf power amplifier module, 9.6GHz vhf power amplifier module, RF uhf power amplifier module


Frequency:	NXPA8.8-9.6GHz-50W	Dimensions(mm)/Weight:	≤171×95×25.5 (without Connectors), ≤600g
Max Output Power (CW):	≥ 47dbm	Temperature Protection:	Over 80℃ Protection，with Open Circuit Protection

Frequency:	NXPA8.8-9.6GHz-50W
Dimensions(mm)/Weight:	≤171×95×25.5 (without Connectors), ≤600g
Max Output Power (CW):	≥ 47dbm
Temperature Protection:	Over 80℃ Protection，with Open Circuit Protection

OEM RF UHF VHF Power Amplifier Module NXPA8.8-9.6GHz-50W

PN:NXPA8.8-9.6GHz-50W

Small size, Low power consumption, good stability;
High linearity and Intermodulation;
Shape structure can be customized
Products can be developed according specification;
Widely used in Radar, Navigation, Communication, EMC test and other Civil fields.

Parameters
Frequency	2G-18GHz
Max output Power (CW)	≥ 8W
Gain	≥ 40dB (customized)
Gain Flatness	≤ 2±1dB
Input power	2±1dBm
Input VSWR	≤ 1.7
Temperature protection	Over 80℃ protection
PTT port	Default off; 3.3~5V on
VCC/Current reference	28V/4A
Working voltage	+28V~ +30V
Working current	≤ 3A
Spurious	≤ -65dBc
Harmonic	harmonics Worst point≤ -10dBc
Operating Temperature	-30℃~+55℃
RF Connector	SMA-F
Power Supply Interface	feedthru capacitor
Dimensions(mm)/Weight	≤56×44×13mm (without connectors), ≤100g
Installation method	Radiator shall be installed for power amplifier test
Package	1pcs/box

Outline Drawing

OEM RF UHF VHF Power Amplifier Module NXPA8.8-9.6GHz-50W 0

Support and Services:

RF Power Amplifier Technical Support and Services

Provide technical guidance on the installation, use and maintenance of RF Power Amplifier.
Provide troubleshooting and repair services.
Provide replacement parts and components.
Answer customer inquiries and provide product information.
Provide technical training for customers.
Provide warranty service.
