Name: NXPA5000 6000MHz 50W UAV Module RF Communication Module
Brand: Nengxun Communication Technology Co.,Ltd.
SKU: NXPA5000-6000MHz-50W
Price: 2,250.00 USD
Availability: InStock

Product Details

Place of Origin: CHINA

Brand Name: NENGXUN

Model Number: NXPA5000-6000MHz-50W

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: The price is negotiable

Packaging Details: 25.6*111.7*17MM

Delivery Time: 5-8DAYS

Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability: 10000

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                6000MHz uav module, RF Communication uav module, UAV rf communication module


Frequency:	NXPA5000-6000MHz-50W	Dimensions(mm)/Weight:	≤232.3×106×24.5 (without Connectors), ≤1.5KG
Max Output Power (CW):	≥ 47dbm	Temperature Protection:	Over 80℃ Protection，with Open Circuit Protection

Frequency:	NXPA5000-6000MHz-50W
Dimensions(mm)/Weight:	≤232.3×106×24.5 (without Connectors), ≤1.5KG
Max Output Power (CW):	≥ 47dbm
Temperature Protection:	Over 80℃ Protection，with Open Circuit Protection

NXPA5000 6000MHz 50W UAV Module RF Communication Module

PN:NXPA5000-6000MHz-50W

Small size, Low power consumption, good stability;
High linearity and Intermodulation;
Shape structure can be customized
Products can be developed according specification;
Widely used in Radar, Navigation, Communication, EMC test and other Civil fields.

NXPA5000 6000MHz 50W UAV Module RF Communication Module 0

Parameters
Frequency	5000MHz~6000MHz
Max output Power (CW)	≥ 47dBm
Gain	≥ 46dB (customized)
Gain Flatness	≤ 2±1dB
Input power	2±1dBm
Input VSWR	≤ 1.7
Temperature protection	Over 80℃ protection
PTT port	Default off; 3.3~5V on
VCC/Current reference	30V/12A
Working voltage	+28V~ +30V
Working current	≤ 7-8A
Spurious	≤ -65dBc
Harmonic	harmonics Worst point≤ -20dBc
Operating Temperature	-30℃~+55℃
RF Connector	SMA-F
Power Supply Interface	feedthru capacitor
Dimensions(mm)/Weight	≤232.3×106×24.5 (without connectors), ≤1.5KG
Installation method	Radiator shall be installed for power amplifier test
Package	1pcs/box

Outline Drawing

NXPA5000 6000MHz 50W UAV Module RF Communication Module 1

Support and Services:

RF Power Amplifier Technical Support and Services

Provide technical guidance on the installation, use and maintenance of RF Power Amplifier.
Provide troubleshooting and repair services.
Provide replacement parts and components.
Answer customer inquiries and provide product information.
Provide technical training for customers.
Provide warranty service.
